Bands from plain tape with rounded off edges to avoid pipe damage.
Threaded screw-bush design guarantees uniform distribution of the radial applied strength.
Tape shows clearly material the band is made of and the clamping field.
W1,W2,W3,W4,W5.
Larger diameters.
Production of 2 and 4 wheels vehicles, special vehicles, agriculture machines, boats, industrial plants and equipment in general.
 |
 |
|
|
W1 |
W2 |
W3 |
W4 |
W5 |
|
SW 7 Philips Screw
|
• |
• |
|
|
|
|
SW 7 Slot Screw
|
|
|
• |
• |
• |
|
Flat Band
|
• |
|
|
|
|
|
Printed Band
|
|
• |
• |
• |
• |
|
Item code |
Field |
XBOX |
Recommended
|
||||
|
W1 |
W2 |
W3 |
W4 |
W5 |
|||
|
|
|
|
|
|
mm |
items |
Nm |
|
F.100.001.1936 |
- |
- |
- |
- |
8-12 |
100 |
2.5 |
|
- |
F.100.025.1936 |
F.100.048.1936 |
- |
- |
8-16 |
100 |
3 |
|
F.100.003.1936 |
- |
- |
F.100.072.1936 |
F.100.095.1936 |
10-16 |
100 |
|
|
F.100.004.1936 |
- |
- |
- |
- |
12-18 |
100 |
|
|
- |
F.100.028.1936 |
F.100.051.1936 |
F.100.074.1936 |
F.100.097.1936 |
12-20 |
100 |
|
|
F.100.006.1936 |
F.100.029.1936 |
F.100.052.1936 |
F.100.075.1936 |
F.100.098.1936 |
12-22 |
100 |
|
|
F.100.007.1936 |
F.100.030.1936 |
F.100.053.1936 |
F.100.076.1936 |
F.100.099.1936 |
16-27 |
100 |
|
|
F.100.008.1936 |
F.100.031.1936 |
F.100.054.1936 |
F.100.077.1936 |
F.100.100.1936 |
20-32 |
100 |
|
|
F.100.009.1936 |
F.100.032.1936 |
F.100.055.1936 |
F.100.078.1936 |
F.100.101.1936 |
23-35 |
100 |
|
|
F.100.010.1936 |
F.100.033.1936 |
F.100.056.1936 |
F.100.079.1936 |
F.100.102.1936 |
25-40 |
100 |
|
|
F.100.011.1936 |
F.100.034.1936 |
F.100.057.1936 |
F.100.080.1936 |
F.100.103.1936 |
30-45 |
100 |
|
|
F.100.012.1936 |
F.100.035.1936 |
F.100.058.1936 |
F.100.081.1936 |
F.100.104.1936 |
35-50 |
50 |
|
|
F.100.013.1936 |
F.100.036.1936 |
F.100.059.1936 |
F.100.082.1936 |
F.100.105.1936 |
40-60 |
50 |
|
|
F.100.014.1936 |
F.100.037.1936 |
F.100.060.1936 |
F.100.083.1936 |
F.100.106.1936 |
50-70 |
50 |
|
|
F.100.015.1936 |
F.100.038.1936 |
F.100.061.1936 |
F.100.084.1936 |
F.100.107.1936 |
60-80 |
25 |
|
|
F.100.016.1936 |
F.100.039.1936 |
F.100.062.1936 |
F.100.085.1936 |
F.100.108.1936 |
70-90 |
25 |
|
|
F.100.017.1936 |
F.100.040.1936 |
F.100.063.1936 |
F.100.086.1936 |
F.100.109.1936 |
80-100 |
25 |
|
|
F.100.018.1936 |
F.100.041.1936 |
F.100.064.1936 |
F.100.087.1936 |
F.100.110.1936 |
90-110 |
25 |
|
|
F.100.019.1936 |
F.100.042.1936 |
F.100.065.1936 |
F.100.088.1936 |
F.100.111.1936 |
100-120 |
loose |
|
|
F.100.020.1936 |
F.100.043.1936 |
- |
F.100.089.1936 |
F.100.112.1936 |
110-130 |
loose |
|
|
F.100.021.1936 |
F.100.044.1936 |
- |
F.100.090.1936 |
F.100.113.1936 |
120-140 |
loose |
|
|
F.100.022.1936 |
F.100.045.1936 |
- |
F.100.091.1936 |
F.100.114.1936 |
130-150 |
loose |
|
|
F.100.023.1936 |
F.100.046.1936 |
- |
F.100.092.1936 |
F.100.115.1936 |
140-160 |
loose |
|
|
TYPE |
MATERIALS |
|
W1 |
All components in Chrome IV free galvanized carbon steel. |
|
W2 |
Band and drawer made of 1.4016/AISI 430 stainless steel. |
|
W3 |
All components in 1.4016/AISI 430 stainless steel. |
|
W4 |
All components in 1.4301/AISI 304 stainless steel. |
|
W5 |
All components in 1.4401/AISI 316 stainless steel. |
