Bands from plain tape with rounded off edges to avoid pipe damage.
Threaded screw-bush design guarantees uniform distribution of the radial applied strength.
Tape shows clearly material the band is made of and the clamping field.
W1,W2,W3,W4,W5.
Larger diameters.
Production of 2 and 4 wheels vehicles, special vehicles, agriculture machines, boats, industrial plants and equipment in general.
 |
 |
|
|
W1 |
W2 |
W3 |
W4 |
W5 |
|
SW 7 Phillips Screw
|
• |
• |
|
|
|
|
SW 7 Slot Screw
|
|
|
• |
• |
• |
|
Flat Band
|
• |
• |
• |
|
|
|
Printed Band
|
|
|
|
• |
• |
|
Item code |
Field |
XBOX |
Recommnded |
||||
|
W1 |
W2 |
W3 |
W4 |
W5 |
|||
|
|
|
|
|
|
mm |
items |
Nm |
|
F.100.116.1936 |
F.100.145.1936 |
F.100.174.1936 |
F.100.203.1936 |
F.100.232.1936 |
16-27 |
50 |
5 |
|
F.100.117.1936 |
F.100.146.1936 |
F.100.175.1936 |
F.100.204.1936 |
F.100.233.1936 |
20-32 |
50 |
|
|
- |
- |
- |
F.100.205.1936 |
F.100.234.1936 |
23-35 |
50 |
|
|
F.100.119.1936 |
F.100.148.1936 |
F.100.177.1936 |
F.100.206.1936 |
F.100.235.1936 |
25-40 |
50 |
|
|
F.100.120.1936 |
F.100.149.1936 |
F.100.178.1936 |
F.100.207.1936 |
F.100.236.1936 |
30-45 |
50 |
|
|
F.100.121.1936 |
F.100.150.1936 |
F.100.179.1936 |
F.100.208.1936 |
F.100.237.1936 |
35-50 |
50 |
|
|
F.100.122.1936 |
F.100.151.1936 |
F.100.180.1936 |
F.100.209.1936 |
F.100.238.1936 |
40-60 |
25 |
|
|
F.100.123.1936 |
F.100.152.1936 |
F.100.181.1936 |
F.100.210.1936 |
F.100.239.1936 |
50-70 |
25 |
|
|
F.100.124.1936 |
F.100.153.1936 |
F.100.182.1936 |
F.100.211.1936 |
F.100.240.1936 |
60-80 |
25 |
|
|
F.100.125.1936 |
F.100.154.1936 |
F.100.183.1936 |
F.100.212.1936 |
F.100.241.1936 |
70-90 |
25 |
|
|
F.100.126.1936 |
F.100.155.1936 |
F.100.184.1936 |
F.100.213.1936 |
F.100.242.1936 |
80-100 |
loose |
|
|
F.100.127.1936 |
F.100.156.1936 |
F.100.185.1936 |
F.100.214.1936 |
F.100.243.1936 |
90-110 |
loose |
|
|
F.100.128.1936 |
F.100.157.1936 |
F.100.186.1936 |
F.100.215.1936 |
F.100.244.1936 |
100-120 |
loose |
|
|
F.100.129.1936 |
F.100.158.1936 |
F.100.187.1936 |
F.100.216.1936 |
F.100.245.1936 |
110-130 |
loose |
|
|
F.100.130.1936 |
F.100.159.1936 |
F.100.188.1936 |
F.100.217.1936 |
F.100.246.1936 |
120-140 |
loose |
|
|
F.100.131.1936 |
F.100.160.1936 |
F.100.189.1936 |
F.100.218.1936 |
F.100.247.1936 |
130-150 |
loose |
|
|
F.100.132.1936 |
F.100.161.1936 |
F.100.190.1936 |
F.100.219.1936 |
F.100.248.1936 |
140-160 |
loose |
|
|
F.100.133.1936 |
F.100.162.1936 |
F.100.191.1936 |
F.100.220.1936 |
F.100.249.1936 |
150-170 |
loose |
|
|
F.100.134.1936 |
F.100.163.1936 |
F.100.192.1936 |
F.100.221.1936 |
F.100.250.1936 |
160-180 |
loose |
|
|
F.100.135.1936 |
- |
F.100.193.1936 |
F.100.222.1936 |
F.100.251.1936 |
170-190 |
loose |
|
|
F.100.136.1936 |
- |
F.100.194.1936 |
F.100.223.1936 |
F.100.252.1936 |
180-200 |
loose |
|
|
F.100.137.1936 |
- |
F.100.195.1936 |
F.100.224.1936 |
F.100.253.1936 |
190-210 |
loose |
|
|
F.100.138.1936 |
- |
- |
- |
- |
200-220 |
loose |
|
|
F.100.139.1936 |
- |
- |
- |
- |
210-230 |
loose |
|
|
F.100.140.1936 |
- |
- |
- |
- |
220-240 |
loose |
|
|
F.100.141.1936 |
- |
- |
- |
- |
230-250 |
loose |
|
|
F.100.142.1936 |
- |
- |
- |
- |
240-260 |
loose |
|
|
F.100.143.1936 |
- |
- |
- |
- |
250-270 |
loose |
|
|
F.100.144.1936 |
- |
- |
- |
- |
260-280 |
loose |
|
|
TYPE |
MATERIALS |
|
W1 |
All components in Chrome VI free galvanized carbon steel . |
|
W2 |
Band and drawer made of 1.4016/AISI 430 stainless steel Chrome IV free galvanized carbon steel screw. |
|
W3 |
All components in 1.4016/AISI 430 stainless steel. |
|
W4 |
All components in 1.4301/AISI 304 stainless steel. |
|
W5 |
All components in 1.4401/AISI 316 stainless steel. |
